WebSharper

WebSharper Extensions for jQuery Mobile Public

A unified, HTML5-based user interface system for all popular mobile device platforms, built on the rock-solid jQuery and jQuery UI foundation.

Library home Browse source code Example

Nuget

Install-Package WebSharper.JQuery.Mobile

Overview

This extension provides WebSharper bindings to the jQuery Mobile library, version 1.3.1, that provides support for mobile web development. The library targets any of the following platforms:

  • iOS
  • Android
  • BlackBerry
  • Bada
  • Windows Phone
  • Palm Web OS
  • Symbian
  • Meego

Creating Pages

JQuery Mobile uses the data-* Html5 attributes to mark each of the elements in the page. It automatically adds CSS classes in order to make them more suitable for mobile development.

One of the most important data attributes is the "role" attribute. The following values are used commonly

  • page: Create pseudo-pages in the same page. This avoids long refreshing times.
  • header: Top part of the page.
  • content: Middle part of the page.
  • footer: Bottom of the page.
  • button: Transforms a link into a button that is easier to target in a touch based application.
  • collapsible: A collapsible element that can be minimized in order to save space

Writing a simple page can be done by simply setting this attributes in the page.

First, some helpers to set the custom attributes to an element:

1
2
3
4
5
6
7
8
9
10
open WebSharper.JQuery

[<JavaScript>]
let SetAttr attr value elem =
    elem
    |>! OnAfterRender (fun elem ->
        JQuery.Of(elem.Body).Attr(attr, value).Ignore)

[<JavaScript>]
let AddDataRole role elem = SetAttr "data-role" role elem

Then it is a matter of adding the right attributes to each of the parts of the website. Since JQuery Mobile works automatically, it is sometimes better to make sure the resource is added to the page. The dummy UseJQueryMobile will force the static analyzer to add the reference of the JQuery Mobile extension.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
open WebSharper.JQuery
open WebSharper.JQuery.Mobile

[<JavaScript>]
let SimplePage () =
    Mobile.Use() // triggers webresource.
    let header =
        Div [H1 [Text "Page Title"]]
        |> AddDataRole "header"

    let content =
        Div [P [Text "Lorem ipsum dolor sit amet, consectetur adipiscing"]]
        |> AddDataRole "content"

    let footer =
        Div [H4 [Text "Page Footer"]]
        |> AddDataRole "footer"

    let page =
        Div [header
             content
             footer]
        |> AddDataRole "page"

  page

Using the jQuery Mobile object

JQuery also exposes some additional events and configuration properties documented in their website. To get access, build the jQuery object under the Mobile namespace. Is possible to build it from any jQuery object as it's shown in the following example:

1
2
3
Mobile.Events.Tap.On(JQuery.Of(header.Body), fun event ->
    JS.Alert("Tapped on: " + string event.PageX + "," + string event.PageY)
)

Configuration properties and utilities

They jQuery Mobile also provides different utilities and configuration values. These are available under the Mobile.Instance property. For example:

1
2
3
open WebSharper.JQuery.Mobile

Mobile.Instance.DefaultPageTransition
