WebSharper Extensions for Sencha Touch Insider Pro

A high-performance HTML5 mobile application framework for building powerful apps that work on iOS, Android, Blackberry, Windows Phone and more.

Library home Example

(Note: separate licensing for Sencha Touch is necessary, consult the Sencha website for more details.)

Nuget

Install-Package WebSharper.SenchaTouch

Sencha Touch is a leading HTML5+JavaScript framework for mobile application development. This matching WebSharper extension brings this powerful library in a type safe manner to F#, enabling developers to author awesome mobile web applications in pure F# code.

Notes on usage

This extension has been automatically generated from the official Sencha Touch documentation. This can sometimes lead to insufficient typing, requiring explicit type annotations in consuming code. The easiest way to do this is by using the As<_> primitive provided by WebSharper.

For the complete API, please consult the official documentation.

Using the WebSharper extensions for Sencha Touch and Ext JS share the same principles and guidelines, outlined in the WebSharper Extensions for Ext JS page.

In addition to that document, the following considerations need your attention:

Changes in API names and casing

  • Ext.version property is renamed to Ext.ExtVersion to avoid naming conflict.

Configuration objects

All Sencha framework components can be created by the function Ext.create by passing it the name of the class and a configuration object, which describes the initial state of the created component. In the WebSharper bindings, these config classes are represented as nested classes in the ExtCfg class. For example this code creates and displays an empty Sencha Touch container in JavaScript:

1
2
3
4
Ext.create('Ext.Container', {
    layout: fit,
    fullscreen: true
}).show();

The straightforward translation to F#:

1
2
3
4
5
6
(Ext.Create(
    ExtCfg.Container(
        Layout = "fit",
        Fullscreen = true
    )
) |> As<Ext.Container>).Show()

ExtCfg.window.Window is the class of the configuration objects for Ext.Container, you can set available config properties with F#'s conscructor with property initializers syntax. Ext.Create returns an obj because it can create any kind of objects, so a cast is necessary. Howewer there is a way to avoid this, a .Create() method is generated for every config object which has the correct JavaScript translation for a call to Ext.create, and the return value is correctly typed, so the above can be rewritten as:

1
2
3
4
ExtCfg.Container(
    Layout = "fit",
    Fullscreen = true
).Create().Show()

When adding additional fields on a config object is needed, the .With method defined on all config object types can help. It has two overloads, for adding a single key-value pair and for copying all the fields from another config object.

Config object properties often can take an array of config objects or already initialized components, even mixing these two. There is no easy way to correctly represent it in .NET, usually the type for the property gets generated as an array of components from the documentation, but you can use As and pass config objects too, without calling .Create() on them.

Using Sencha Touch in a WebSharper project

Use a class inheriting WebSharper's Web.Control class like this, and use it in a sitelet:

1
2
3
4
5
6
7
type AppControl() =
    inherit Web.Control()

    [<JavaScript>]
    override this.Body =
        Ext.Application(ExtParam.ApplicationConfig(Launch = As onLaunch))
        upcast Div []

In the function onLaunch, create a container, for example an ExtCfg.Container with FullScreen = true to have a full screen container that you can use for your mobile application.

Adding themes

The senchatouch-all.js file is automatically included in the HTML+JavaScript package created with the Sencha Touch binding. You have to specify which css (theme) you want to use by using a Require attribute, for example [<Require(typeof<Resources.SenchaTouchCss>)>].
